80*25MM UHF ABS Asset anti-metal tag

Model NR-8724 Protocol EPC Class1 Gen2; ISO18000-6C frequency 860-960MHz Chip Alien Ucode 9 memory EPC96bitsTID 96bits Kill password 32bit Work Read and Writer memory lead time 50years Warranty 1year Material ABS Color black,grey ,white ,bu

Model number：
Power：
Colour：
Dimension：
Weight：

CONTACT NOW down load to pdf

Product Details

Model	NR-8724
Protocol	EPC Class1 Gen2; ISO18000-6C
frequency	860-960MHz
Chip	Alien Ucode 9
memory	EPC96bits TID 96bits Kill password 32bit
Work	Read and Writer
memory lead time	50 years
Warranty	1year
Material	ABS
Color	black,grey ,white ,bule,red customized
Size	872412mm
Temperature	-25℃~ +85℃
Storage temperature	-30℃~ +110℃
Save humidity	5%～95%
Adhesive	3M 300LSE
weight	1g
package	500pcs/bag
Alcohol test	95%Concentration alcohol test passed
High and low temperature alternating test	-40℃ to +80℃ 7 times high and low temperature alternating cycle, a total of 2 consecutive days passed the test
RoHS	yes
IP degree	IP65
Handheld reader on metal surface 5dbi antenna	0-8Meter Reading distance is related to environment and reader performance
Fixed UHF RFID Reader (12dbi antenna)	0-20meter Reading distance is related to environment and reader performance
Polarization direction	Linear Polarization
Text	100% tested it before we send out
