Operating Frequency |
866-868Mhz EU, 902-928Mhz US |
|
Protocol |
ISO18000-6C (EPC Class1 Gen2) |
|
Working Mode |
FHSS/Fixed frequency |
|
Antenna Port |
4 TNC connector |
|
Rf Output |
10dBm~33dBm (@1dBm per step) |
|
Reading Range |
0~20m (depends on antenna and tag type) |
|
Writing Range |
0~3m (depends on antenna and tag type) |
|
Reading Speed |
300pcs/s |
|
Communication Port |
TCP/IP (Ethernet), RS232/RS485 |
|
Io Port |
2 channel relay output, 1channel photoelectric isolation input |
|
Power Supply |
DC 12V/3A |
|
Material |
Aluminum alloy |
|
Dimension |
240mm(L) x 180mm(W) x 28mm(H) |
|
Weight |
865g |
|
Working Temperature |
-20℃~ 65℃ |
|
Storage Temperature |
-30℃~ 75℃ |
|
Humidity |
5%~95% (non-condensing) |
|
Waterproof |
IP67 |
