RFID FLEXIBLE TIRE TAG FOR VEHICLE TRACKING 860-960Mhz

Flexible Tire Tag is specially developed for tire tracking and vehicle management.Flexible Tire Tag complies with ISO18000-6C standard and work at frequency of 860~960MHz. This tag is normally embedded with Impinj Monza 4QT or Alien H3 or upon client's request.Mysky's Flexible Tire Tag is made at a smart size and it can be easily patched onto the sidewall of the tire with vulcanizing agent and wor···

Model number：
Power：
Colour：
Dimension：
Weight：

CONTACT NOW down load to pdf

Product Details

Flexible Tire Tag is specially developed for tire tracking and vehicle management.
Flexible Tire Tag complies with ISO18000-6C standard and work at frequency of 860~960MHz. This tag is normally embedded with Impinj Monza 4QT or Alien H3 or upon client's request.
Flexible Tire Tag is made at a smart size and it can be easily patched onto the sidewall of the tire with vulcanizing agent and work reliably throughout a tire's whole lifetime.

Product Applications:
Bus/truck tire tracking, automobile factory tire tracking, logistic vehicle management etc.,

Product Code	NR-9535
Product Name	Flexible Tire Tag
Electronic Parameter
Working Frequency	860~960MHz
Chip	Impinj 4QT or upon client's request
Protocol	ISO18000-6C
Memory	EPC 128bits; User 512bits; TID 48bits;
Read/Write Endurance	100,000 times
Data Retention	> 10 years
Read Distance	1.08M (2W ERP)
Physical Property
Dimension & Weight	95x35x2mm, 8g/pcs
Mounting Method	self-adhesive
Affixes To	rubber tire
Material	rubber
Survive Temperature	-40°C to +230° C
Operating Temperature	-40°C to +85° C
Customization	printing and encoding upon request
Packing Details
Bag Qty		100pcs/bag
Carton Qty		32 bags total 3,200pcs in carton
Net Weight
Gross Weight
Carton Size		50x45x35cm
