860-960Mhz UHF Laundry Tag With Metal Eyelet

Model number：
Power：
Colour：
Dimension：
Weight：

CONTACT NOW down load to pdf

Product Details

UHF Laundry Tag With Metal Eyelet is specially designed for textile/linen product tracking in laundry industry or uniform rental industry. The tag has a metal eyelet so it can be easily fixed onto a textile products through threads or strings. The tag lasts more than 200 wash & dry cleaning cycles.
UHF Laundry Tag With Metal Eyelet complies with ISO18000-6C standard and work at frequency of 860~960MHz. This tag is normally embedded with NXP Ucode7M chip or upon client's request.
UHF Laundry Tag With Metal Eyelet Laundry Tag is made at a size of 75x15mm or upon client's request.

Product Applications:

Digital laundry, linen product management at hotel/Spa/Club/Healthcare, Uniform management, Rental Industry etc.

Compliance	EPC Class1 Gen2; ISO18000-6C
Frequency	902-928MHz , 865~868MHz (Can customize frequency)
Chip	NXP Ucode7M / Ucode8
Memory	EPC 96bits
Read/write	Yes (EPC)
Data Storage	20 years
Lifetime	200 wash cycles or 2 years from shipping date (whichever comes first)
Material	Textile
Dimension	75( L) x 15( W) x 1.5( H) (Cancustomizethesizes)
Storage Temperature	-40℃~ +85 ℃
Operating Temperature	1) Washing: 90℃(194οF), 15 minutes, 200 cysle 2) Pre-drying in Tumbler: 180℃(320οF), 30minutes 3) Ironer: 180℃(356οF), 10 seconds, 200 cycles 4) Sterilization Process: 135℃(275οF), 20 minutes
Mechanical Resistance	Up to 60 bars
Delivery format	Single
Installation Method	sewing or cable tie
Weight	~ 0.7g
Package	Antistatic bag and carton
Color	White
Power Supply	Passive
Chemicals	Normal common chemicals in the washing processes
RoHS	Compatible
Read distance	Up to 5.5 meters (ERP=2W) Upto 2 meters( With ATIDAT880handheldreader)
Polarization	Liner
