30*15MM UHF RFID Soft Flexible Printable Anti-metal Tag

Model NR-5015 Protocol EPC Class1 Gen2; ISO18000-6C Dimensions(mm) 50x5x1.26MM frequency 860-960MHz Chip Alien Ucode 9 or Impinj R6-P memory Ucode 9 :EPC96bitsTID 96bits kill password 32-bit Work Read and Writer memory lead time 50years War

Model number：
Power：
Colour：
Dimension：
Weight：

CONTACT NOW down load to pdf

Product Details

Model	NR-3015
Protocol	EPC Class1 Gen2; ISO18000-6C
Dimensions(mm)	30x15x1.26MM
frequency	860-960MHz
Chip	Alien Ucode 9 or Impinj R6-P
memory	Ucode 9 :EPC96bits TID 96bits kill password 32-bit
Work	Read and Writer
memory lead time	50 years
Warranty	1year
Surface Material	White PET
Print Performance	Excellent
Printer	Zebra RZ400/R110Xi4, SATO CL4NX,Toshiba SX-5
Temperature	40°F to +185°F (-40°C to + 85°C)
Storage temperature	40°F to +185°F (-40°C to + 85°C)
Printable	color logo, QR/barcode/serial number encoding EPC etc
Adhesive	Nornal or 3M 300LSE
weight	0.6g/pcs
package	500pcs/bag
Alcohol test	95%Concentration alcohol test passed
Package	500pcs/Roll
RoHS	yes
IP degree	IP65
Handheld reader on metal surface (4dbi)	0-3Meter (Reading distance is related to environment and reader performance)
Fixed RFID Reader (12dbi long range )	0-5Meter (Reading distance is related to environment and reader performance)
Polarization direction	Linear Polarization
Text	100% tested it before we send out
